| Specifications |
| Body Style: |
Wafer, Lug and Double Flanged |
| Size Range: |
2 1/2″ – 66″ (65mm – 1650mm) |
| Temperature Range: |
-62°F to 500°F (-52°C to 260°C) |
| Pressure Ratings: |
ASME Class 150, 300 and 600 |
| Shutoff Rating: |
Zero Leakage |
| Body Materials: |
Carbon Steel, Stainless Steel, Nickel Aluminum Bronze |
| Disc Material: |
Stainless Steel, Nickel Aluminum Bronze |
| Stem Materials: |
Stainless Steel, Monel K500 |
| Seat Materials: |
Standard – RTFE with Resilient Energizer, PTFE with Resilient Energizer Fire Safe – RTFE and Inconel with Resilient Energizer |
| Applications: |
High Pressure, High Temperature, Critical Service |
| Fugitive Emissions: |
TA-Luft |
